Modular Living Space – Code PCUE0004
External Dimensions: 9000 × 4500 × 2400 mm (interior height) (2 Modular Units)
Usable Area: 31 m²
Thermal Insulation: 60 mm PUR sandwich panels.
Walls: 60 mm PUR sandwich panels; interior finish RAL9002, exterior finish RAL9002.
Roof: 60 mm PUR sandwich panel, RAL9002.
Floor: Thermally insulated with mineral wool; finished with heavy-duty linoleum.
Electrical Installation: Included, with LED lighting system.
Steel Frame: Special-profile galvanized steel with integrated hidden drainage; coated with primer and weather-resistant paint.
Doors & Windows: PVC frames with double-glazed units.
Options (on request): WC cabin with sanitary installation.
Suggested Applications:
Studio Cabin – Self-contained 20–30 m² with kitchenette and shower; ideal as a weekend retreat.
One-Bedroom Tiny Home – Separate bedroom plus living/kitchen; great as a backyard ADU/annex.
Family Lodge (2 modules combined) – 2 bedrooms, bathroom and open-plan living for short or long stays.
Two-Storey Holiday Home (P+1) – Compact upstairs bedrooms with ground-floor living and terrace.
Guest House / Granny Annex – Independent accommodation for family or carers; can be built to Part M accessibility.
Rental Chalet / Holiday Let – Durable finishes for high turnover; smart storage and easy maintenance.
Glamping Pod / Eco-Lodge – Off-grid options (solar, battery, rainwater, composting WC) for nature stays.
Lake or Mountain Retreat – Panoramic glazing, insulation upgrade and deck for scenic locations.
Student or Micro-Apartment – Efficient layout with en-suite, kitchenette and built-in wardrobes.
Seasonal Worker Housing – Bunk or twin layouts with shared sanitary module and laundry.
Wellness Cabin – Sauna + shower and relaxation room; can pair with an outdoor hot-tub deck.
Beach Bungalow – Salt-resistant finishes, outside shower and covered veranda for coastal rentals.
